SMALL PARTS for wires and sheathing | ||||
| Code nos. | Description | ||||
|
F154.TR42 |
 |
Assorted small parts chest contains the total assortment of small parts in the present price list to a total of 1796 pcs. (Refer to the list to find out the quantity of each type ). | |||
| F155.0 |  |
Cycle clamp | |||
| F155.1 |  |
Cycle regulator | |||
| F155 |  |
Carburettor clamp | |||
| F156 |  |
Practic clamp | |||
| F156.1 |  |
Clamp with grain | |||
| F157 |  |
Clamp with top screw Æ 5,5x9 | |||
| F158 | Clamp with top screw Æ 8 | ||||
| F159 | Clamp with top screw Æ 10 | ||||
| F160 |  |
Clamp with top screw Æ 10x22 hexagon Æ 12 Pasbo | |||
| F160.1 | Clamp with top screw Æ 10x21 hexagon Æ 12 mowers etc. | ||||
| F161 |  |
Clamp with side screw Æ 7 | |||
| F162 | Clamp with side screw Æ 8 | ||||
| F163 | Clamp with side screw Æ 9 | ||||
| F164 | Clamp with side screw Æ 10 | ||||
| F165 | Clamp with side screw Æ 12 | ||||
| F166 |  |
Clamp with two side screws Æ 12x20 | |||
| F166.1 |  |
Clamp with two side screws Æ 12x25 with tang | |||
| F167 |  |
Clamp Vespa gear change | |||
| F167.HP | Clamp Vespa gear change HP | ||||
| F168 |  |
Clamp Ape MP gear change | |||
| F169 |  |
Clamp Garelli and to substitute holder ( for example on valve lifter lever Ciao - Si - Bravo etc.) | |||
| F170 |  |
Clamp motorcycle brake | |||
| F170.1 |  |
Clamp motorcycle brake Piaggio Ciao - Si - Bravo etc. | |||
| F171 |  |
Clamp Vespa front brake | |||
| F172 | Clamp Vespa back brake | ||||
 |
|||||
| F172.TM | Clamp clutch pin Ape 601- TM- CAR - Scooter – with loop for single line assembly maintaining original adjustment and look. | ||||
| F173 |
|
Cover for sheath Æ 3,9 | |||
| F174 | Cover for sheath Æ 4,5 | ||||
| F175 | Cover for sheath Æ 5 | ||||
| F176 | Cover for sheath Æ 6 | ||||
| F176.0T.14 | Cover for sheath Æ 6,8 X 14 brass | ||||
| F177 | Cover for sheath Æ 7 | ||||
| F178 | Cover for sheath Æ 8 | ||||
| F178.1 | Cover for sheath Æ 9 | ||||
| F178.2 | Cover for sheath Æ 10 | ||||
| F178.3 | Cover for sheath Æ 12 | ||||
| F179 |  |
Bush Æ 7x9 turned | |||
| F179.1 |  |
Bush Æ 7x9 in pressed metal allows double use of bush plus sheath cover. | |||
| F180 |  |
Bush Æ 8x11 turned | |||
| F181 | Bush Æ 9x15 turned | ||||
| F181.0 | Bush Æ 9x17 turned | ||||
| F181.1 | Bush Æ 9x22 turned with lip Æ 4,5x10 | ||||
| F182 | Bush Æ 9x20 (Ape MP) | ||||
| F183 | Bush Æ 10x16 turned | ||||
| F183.1 | Bush Æ 10x17 turned | ||||
| F184 | Bush Æ 11x17 turned | ||||
| F184.1 | Bush Æ 11x17 turned with collar | ||||
| F185 | Bush Æ 12x17 turned | ||||
| F185.1 | Bush Æ 12x21 turned reduction Æ 6x7 | ||||
| F185.2 | Bush Æ 21x22 turned reduction Æ 9,8x8 | ||||
| F186 |  |
Bush conical milled Æ 9 | |||
| F187 | Bush conical milled Æ 10 | ||||
| F188 |  |
Bull Vespa Æ 8x8,5 milled | |||
| F188.1 | Bull Æ 9,5x9 Vespa PK milled | ||||
| F188.A |  |
Bull
Æ 10x14 loop
to thread through all.
Round ended agricultural wire (transforming in bull head) with the added quality of being jointed |
|||
| F189 |  |
Cover Vespa PK - Ape 50 | |||
| F189.1 |  |
Cover Vespa PX | |||
| F190 |  |
Cover motorcycle milled Æ 10x16 | |||
| F190.1 | Cover motorcycle milled Æ 10x19 with split pin hole | ||||
| F191 |  |
Cover agricultural milled Æ 12x20 | |||
| F191.0 |  |
Cover
agricultural Æ
12x20 with cable holes plus split pin holes
(without milling) |
|||
| F191.1B |  |
Cover agricultural milled Æ 12x18 with split pin hole | |||
| F191.1 | Cover agricultural milled Æ 12x20 with split pin hole | ||||
| F191.2 |  |
Cover cable holes for line Pasbo eyelet | |||
| F192 |  |
Regulator Æ 5 MA x 25 hexagonal Æ 8 | |||
| F192.1 | Regulator Æ 5 MA x 31 hexagonal Æ 8 with 2 nuts | ||||
| F192.2 | Regulator Æ 5 MA x 36 hexagonal Æ 8 | ||||
| F193 | Regulator Æ 6 MA x30 hexagonal Æ 8 | ||||
| F193.1 | Regulator Æ 6 MA x 34 hexagonal Æ 10 | ||||
| F194 | Regulator Æ 6 MA x 40 hexagonal Æ 8 | ||||
| F194.1 | Regulator Æ 6 MA x 40 hexagonal Æ 10 | ||||
| F195 | Regulator Æ 6 MA x 40 hexagonal Æ 10 holes for sheath Æ 7 . | ||||
| F192.S |  |
Regulator pressed Æ 5 MA x 24,5 lined head | |||
| F193.S | Regulator pressed Æ 6 MA x 24,5 lined head | ||||
| F196 |  |
Regulator Æ 7 MA x 30 hexagonal Æ 8 | |||
| F197 | Regulator Æ 7 MA x 35 hexagonal Æ 10 | ||||
| F198 | Regulator Æ 8 MA x 35 hexagonal Æ 12 | ||||
| F199 | Regulator Æ 8 MA x 40 hexagonal Æ 12 | ||||
| F200 | Regulator Æ 8 MA x 50 hexagonal Æ 12 | ||||
| F201 | Regulator Æ 8 MA (1)x 50 hexagonal Æ 10 | ||||
| F204 | Regulator Æ 10 MA x 52 hexagonal Æ 14 | ||||
| F206 | Regulator Æ 12 MA x 60 hexagonal Æ 17 | ||||
| F208 |  |
Safety ending for wires Æ 2,1 | |||
| F209 | Safety ending for wires Æ 2,7 | ||||
  |
|||||
| F210 | Carburettor curve 24 x 46 regulator Æ 22 | ||||
| F211 | Carburettor curve 21 x 21 regulator Æ 22 | ||||
| F212 | Carburettor curve 21 x 21 regulator Æ 22 | ||||
| WATCH OUT !!! For other products not listed here we need the exact technical measurements or else a sample of an already existing type. | |||||
